以Nginx的为例，当任意一个Nginx挂掉，其处理的逻辑是相同的，即仅需重新创建一个Pod副本即可，这类服务我们称之为无状态服务。
以MySQL主从同步为例，master，slave两个库任意一个库挂掉，其处理逻辑是不相同的，这类服务我们称之为有状态服务。
有状态服务面临的难题:
(1)启动/停止顺序;
(2)pod实例的数据是独立存储;
(3)需要固定的IP地址或者主机名;
<font color="#9bbb59">StatefulSet一般用于有状态服务，StatefulSets对于需要满足以下一个或多个需求的应用程序很有价值。</font>
<font color="#9bbb59"> (1)稳定唯一的网络标识符。</font>
<font color="#9bbb59"> (2)稳定独立持久的存储。</font>
<font color="#9bbb59"> (3)有序优雅的部署和缩放。</font>
<font color="#9bbb59"> (4)有序自动的滚动更新。 </font>
<font color="#9bbb59"> </font>
<font color="#9bbb59"> </font>
<font color="#9bbb59">稳定的网络标识:</font>
<font color="#9bbb59"> 其本质对应的是一个service资源，只不过这个service没有定义VIP，我们称之为headless service，即"无头服务"。</font>
<font color="#9bbb59"> 通过"headless service"来维护Pod的网络身份，会为每个Pod分配一个数字编号并且按照编号顺序部署。</font>
<font color="#9bbb59"> 综上所述，无头服务（"headless service"）要求满足以下两点:</font>
<font color="#9bbb59"> (1)将svc资源的clusterIP字段设置None，即"clusterIP: None";</font>
<font color="#9bbb59"> (2)将sts资源的serviceName字段声明为无头服务的名称;</font>
<font color="#9bbb59"> </font>
<font color="#9bbb59"> </font>
<font color="#9bbb59">独享存储:</font>
<font color="#9bbb59"> Statefulset的存储卷使用VolumeClaimTemplate创建，称为"存储卷申请模板"。</font>
<font color="#9bbb59"> 当sts资源使用VolumeClaimTemplate创建一个PVC时，同样也会为每个Pod分配并创建唯一的pvc编号，每个pvc绑定对应pv，从而保证每个Pod都有独立的存储。</font>
1 StatefulSets控制器-网络唯一标识之headless
[root@master231 statefulsets]# cat 01-statefulset-headless-network.yaml
apiVersion: v1
kind: Service
metadata:
name: svc-headless
spec:
ports:
- port: 80
name: web
# 将clusterIP字段设置为None表示为一个无头服务，即svc将不会分配VIP。
clusterIP: None
selector:
app: nginx
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
name: sts-xiuxian
spec:
selector:
matchLabels:
app: nginx
# 声明无头服务
serviceName: svc-headless
replicas: 3
template:
metadata:
labels:
app: nginx
spec:
containers:
- name: nginx
image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
imagePullPolicy: Always
[root@master231 statefulsets]#
[root@master231 statefulsets]# kubectl apply -f 01-statefulset-headless-network.yaml
service/svc-headless created
statefulset.apps/sts-xiuxian created
[root@master231 statefulsets]#
[root@master231 statefulsets]# kubectl get sts,svc,po -o wide
NAME READY AGE CONTAINERS IMAGES
statefulset.apps/sts-xiuxian 3/3 8s nginx registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE SELECTOR
service/kubernetes ClusterIP 10.200.0.1 <none> 443/TCP 10d <none>
service/svc-headless ClusterIP None <none> 80/TCP 8s app=nginx
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
pod/sts-xiuxian-0 1/1 Running 0 8s 10.100.203.186 worker232 <none> <none>
pod/sts-xiuxian-1 1/1 Running 0 6s 10.100.140.87 worker233 <none> <none>
pod/sts-xiuxian-2 1/1 Running 0 4s 10.100.160.134 master231 <none> <none>
[root@master231 statefulsets]#
2.2 测试验证!!!
[root@master231 statefulsets]# kubectl exec -it sts-xiuxian-0 -- sh
/ # ping sts-xiuxian-1.svc-headless -c 3
2 StatefulSets控制器-独享存储
3.1 编写资源清单
[root@master231 statefulsets]# cat 02-statefulset-headless-volumeClaimTemplates.yaml
apiVersion: v1
kind: Service
metadata:
name: svc-headless
spec:
ports:
- port: 80
name: web
clusterIP: None
selector:
app: nginx
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
name: sts-xiuxian
spec:
selector:
matchLabels:
app: nginx
serviceName: svc-headless
replicas: 3
# 卷申请模板，会为每个Pod去创建唯一的pvc并与之关联哟!
volumeClaimTemplates:
- metadata:
name: data
spec:
accessModes: [ "ReadWriteOnce" ]
# 声明咱们自定义的动态存储类，即sc资源。
storageClassName: "cmy-sc-xixi"
resources:
requests:
storage: 2Gi
template:
metadata:
labels:
app: nginx
spec:
containers:
- name: nginx
image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
ports:
- containerPort: 80
name: xiuxian
volumeMounts:
- name: data
mountPath: /usr/share/nginx/html
---
apiVersion: v1
kind: Service
metadata:
name: svc-sts-xiuxian
spec:
type: ClusterIP
clusterIP: 10.200.0.200
selector:
app: nginx
ports:
- port: 80
targetPort: xiuxian
[root@master231 statefulsets]#
3.2 测试验证
[root@master231 statefulsets]# kubectl apply -f 02-statefulset-headless-volumeClaimTemplates.yaml
service/svc-headless created
statefulset.apps/sts-xiuxian created
service/svc-sts-xiuxian created
[root@master231 statefulsets]#
[root@master231 statefulsets]# kubectl get sts,svc,po -o wide
NAME READY AGE CONTAINERS IMAGES
statefulset.apps/sts-xiuxian 3/3 6s nginx registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE SELECTOR
service/kubernetes ClusterIP 10.200.0.1 <none> 443/TCP 10d <none>
service/svc-headless ClusterIP None <none> 80/TCP 6s app=nginx
service/svc-sts-xiuxian ClusterIP 10.200.0.200 <none> 80/TCP 6s app=nginx
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
pod/sts-xiuxian-0 1/1 Running 0 6s 10.100.203.163 worker232 <none> <none>
pod/sts-xiuxian-1 1/1 Running 0 5s 10.100.140.92 worker233 <none> <none>
pod/sts-xiuxian-2 1/1 Running 0 3s 10.100.160.132 master231 <none> <none>
[root@master231 statefulsets]#
[root@master231 statefulsets]# kubectl exec -it sts-xiuxian-0 -- sh
/ # echo AAA > /usr/share/nginx/html/index.html
/ #
[root@master231 statefulsets]#
[root@master231 statefulsets]# kubectl exec -it sts-xiuxian-1 -- sh
/ # echo BBB > /usr/share/nginx/html/index.html
/ #
[root@master231 statefulsets]#
[root@master231 statefulsets]# kubectl exec -it sts-xiuxian-2 -- sh
/ # echo CCC > /usr/share/nginx/html/index.html
/ #
[root@master231 statefulsets]#
[root@master231 statefulsets]# for i in `seq 10`; do curl 10.200.0.200; done
CCC
BBB
AAA
CCC
BBB
AAA
CCC
BBB
AAA
CCC
3 sts的分段更新
4.1.编写资源清单
[root@master231 statefulsets]# cat > 03-statefuleset-updateStrategy-partition.yaml <<EOF
apiVersion: v1
kind: Service
metadata:
name: sts-headless
spec:
ports:
- port: 80
name: web
clusterIP: None
selector:
app: web
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
name: cmy-sts-web
spec:
# 指定sts资源的更新策略
updateStrategy:
# 配置滚动更新
rollingUpdate:
# 当编号小于3时不更新，说白了，就是Pod编号大于等于3的Pod会被更新!
partition: 3
selector:
matchLabels:
app: web
serviceName: sts-headless
replicas: 5
template:
metadata:
labels:
app: web
spec:
containers:
- name: c1
ports:
- containerPort: 80
name: xiuxian
image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
---
apiVersion: v1
kind: Service
metadata:
name: cmy-sts-svc
spec:
selector:
app: web
ports:
- port: 80
targetPort: xiuxian
EOF
4.2.验证
[root@master231 statefulsets]# kubectl get pods -o wide
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
cmy-sts-web-0 1/1 Running 0 30s 10.100.203.183 worker232 <none> <none>
cmy-sts-web-1 1/1 Running 0 28s 10.100.140.102 worker233 <none> <none>
cmy-sts-web-2 1/1 Running 0 28s 10.100.160.180 master231 <none> <none>
cmy-sts-web-3 1/1 Running 0 26s 10.100.203.185 worker232 <none> <none>
cmy-sts-web-4 1/1 Running 0 25s 10.100.140.93 worker233 <none> <none>
[root@master231 statefulsets]#
[root@master231 statefulsets]# kubectl get pods -l app=web -o yaml | grep "\- image:"
- image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
- image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
- image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
- image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
- image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
[root@master231 statefulsets]#
[root@master231 statefulsets]# grep hangzhou 03-statefuleset-updateStrategy-partition.yaml
image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
[root@master231 statefulsets]#
[root@master231 statefulsets]# sed -i '/hangzhou/s#v1#v2#' 03-statefuleset-updateStrategy-partition.yaml
[root@master231 statefulsets]#
[root@master231 statefulsets]# grep hangzhou 03-statefuleset-updateStrategy-partition.yaml
image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v2
[root@master231 statefulsets]#
[root@master231 statefulsets]# kubectl apply -f 03-statefuleset-updateStrategy-partition.yaml
service/sts-headless unchanged
statefulset.apps/cmy-sts-web configured
service/cmy-sts-svc unchanged
[root@master231 statefulsets]#
[root@master231 statefulsets]# kubectl get pods -o wide
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
cmy-sts-web-0 1/1 Running 0 2m23s 10.100.203.183 worker232 <none> <none>
cmy-sts-web-1 1/1 Running 0 2m21s 10.100.140.102 worker233 <none> <none>
cmy-sts-web-2 1/1 Running 0 2m21s 10.100.160.180 master231 <none> <none>
cmy-sts-web-3 1/1 Running 0 12s 10.100.203.174 worker232 <none> <none>
cmy-sts-web-4 1/1 Running 0 14s 10.100.140.101 worker233 <none> <none>
[root@master231 statefulsets]#
[root@master231 statefulsets]# kubectl get pods -l app=web -o yaml | grep "\- image:"
- image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
- image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
- image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v1
- image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v2
- image: registry.cn-hangzhou.aliyuncs.com/cmy-k8s/apps:v2
[root@master231 statefulsets]#
4 基于sts部署zookeeper集群
5.1 K8S所有节点导入镜像
wget http://192.168.14.253/Resources/Kubernetes/Case-Demo/cmy-kubernetes-zookeeper-v1.0-3.4.10.tar.gz
docker load -i cmy-kubernetes-zookeeper-v1.0-3.4.10.tar.gz
5.2 编写资源清单
cat 04-sts-zookeeper.yaml
apiVersion: v1
kind: Service
metadata:
name: zk-hs
labels:
app: zk
spec:
ports:
- port: 2888
name: server
- port: 3888
name: leader-election
clusterIP: None
selector:
app: zk
---
apiVersion: v1
kind: Service
metadata:
name: zk-cs
labels:
app: zk
spec:
ports:
- port: 2181
name: client
selector:
app: zk
---
apiVersion: policy/v1
# 此类型用于定义可以对一组Pod造成的最大中断，说白了就是最大不可用的Pod数量。
# 一般情况下，对于分布式集群而言，假设集群故障容忍度为N，则集群最少需要2N+1个Pod。
kind: PodDisruptionBudget
metadata:
name: zk-pdb
spec:
# 匹配Pod
selector:
matchLabels:
app: zk
# 最大不可用的Pod数量。这意味着将来zookeeper集群，最少要2*1 +1 = 3个Pod数量。
maxUnavailable: 1
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
name: zk
spec:
selector:
matchLabels:
app: zk
serviceName: zk-hs
replicas: 3
updateStrategy:
type: RollingUpdate
podManagementPolicy: OrderedReady
template:
metadata:
labels:
app: zk
spec:
tolerations:
- key: node-role.kubernetes.io/master
operator: Exists
effect: NoSchedule
affinity:
podAntiAffinity:
requiredDuringSchedulingIgnoredDuringExecution:
- labelSelector:
matchExpressions:
- key: "app"
operator: In
values:
- zk
topologyKey: "kubernetes.io/hostname"
containers:
- name: kubernetes-zookeeper
imagePullPolicy: IfNotPresent
image: "registry.k8s.io/kubernetes-zookeeper:1.0-3.4.10"
resources:
requests:
memory: "1Gi"
cpu: "0.5"
ports:
- containerPort: 2181
name: client
- containerPort: 2888
name: server
- containerPort: 3888
name: leader-election
command:
- sh
- -c
- "start-zookeeper \
--servers=3 \
--data_dir=/var/lib/zookeeper/data \
--data_log_dir=/var/lib/zookeeper/data/log \
--conf_dir=/opt/zookeeper/conf \
--client_port=2181 \
--election_port=3888 \
--server_port=2888 \
--tick_time=2000 \
--init_limit=10 \
--sync_limit=5 \
--heap=512M \
--max_client_cnxns=60 \
--snap_retain_count=3 \
--purge_interval=12 \
--max_session_timeout=40000 \
--min_session_timeout=4000 \
--log_level=INFO"
readinessProbe:
exec:
command:
- sh
- -c
- "zookeeper-ready 2181"
initialDelaySeconds: 10
timeoutSeconds: 5
livenessProbe:
exec:
command:
- sh
- -c
- "zookeeper-ready 2181"
initialDelaySeconds: 10
timeoutSeconds: 5
volumeMounts:
- name: datadir
mountPath: /var/lib/zookeeper
securityContext:
runAsUser: 1000
fsGroup: 1000
volumeClaimTemplates:
- metadata:
name: datadir
spec:
accessModes: [ "ReadWriteOnce" ]
resources:
requests:
storage: 10Gi
5.3 实时观察Pod状态
[root@master231 statefulsets]# kubectl apply -f 04-sts-zookeeper.yaml
service/zk-hs created
service/zk-cs created
poddisruptionbudget.policy/zk-pdb created
statefulset.apps/zk created
[root@master231 statefulsets]# kubectl get pods -o wide -w -l app=zk
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
zk-0 1/1 Running 0 101s 10.100.140.108 worker233 <none> <none>
zk-1 1/1 Running 0 88s 10.100.203.190 worker232 <none> <none>
zk-2 1/1 Running 0 65s 10.100.209.62 master-231 <none> <none>
5.4 检查后端的存储
[root@master231 ~]# kubectl get pods -o wide
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
zk-0 1/1 Running 0 85s 10.100.140.125 worker233 <none> <none>
zk-1 1/1 Running 0 63s 10.100.160.189 master231 <none> <none>
zk-2 1/1 Running 0 42s 10.100.203.188 worker232 <none> <none>
[root@master231 ~]#
[root@master231 ~]# kubectl get pvc -l app=zk
NAME STATUS VOLUME CAPACITY ACCESS MODES STORAGECLASS AGE
datadir-zk-0 Bound pvc-b6072f27-637a-4c5d-9604-7095c8143f15 10Gi RWO nfs-csi 43m
datadir-zk-1 Bound pvc-10fdeb29-70b9-41a6-ae8c-f3b540ffcbdc 10Gi RWO nfs-csi 42m
datadir-zk-2 Bound pvc-db936b79-be79-4155-b2d0-ccc05a7e4531 10Gi RWO nfs-csi 37m
[root@master231 ~]#
5.5.验证集群是否正常
[root@master231 sts]# for i in 0 1 2; do kubectl exec zk-$i -- hostname; done
zk-0
zk-1
zk-2
[root@master231 sts]#
[root@master231 sts]# for i in 0 1 2; do echo "myid zk-$i";kubectl exec zk-$i -- cat /var/lib/zookeeper/data/myid; done
myid zk-0
1
myid zk-1
2
myid zk-2
3
5.6 创建数据测试
5.6.1 在一个Pod写入数据
[root@master231 statefulsets]# kubectl exec -it zk-1 -- zkCli.sh
...
[zk: localhost:2181(CONNECTED) 0] ls /
[zookeeper]
[zk: localhost:2181(CONNECTED) 1]
[zk: localhost:2181(CONNECTED) 1]
[zk: localhost:2181(CONNECTED) 1] create /school cmy
Created /school
[zk: localhost:2181(CONNECTED) 2]
[zk: localhost:2181(CONNECTED) 2] create /school/linux97 XIXI
Created /school/linux97
[zk: localhost:2181(CONNECTED) 3]
[zk: localhost:2181(CONNECTED) 3] ls /
[zookeeper, school]
[zk: localhost:2181(CONNECTED) 4]
[zk: localhost:2181(CONNECTED) 4] ls /school
[linux97]
[zk: localhost:2181(CONNECTED) 5]
5.6.2 在另一个Pod查看下数据
[root@master231 statefulsets]# kubectl exec -it zk-2 -- zkCli.sh
...
[zk: localhost:2181(CONNECTED) 0] ls /
[zookeeper, school]
[zk: localhost:2181(CONNECTED) 1] get /school/linux97
XIXI
温馨提示:
业界对于sts控制器有点望而却步，我们知道这个控制器用做有状态服务部署，但是我们不用~
于是coreOS公司有研发出来了Operator(sts+crd)框架，大家可以基于该框架部署各种服务。
